Properties:
1. OMEN Select high quality pure teflon film , with a special surface treatment and then coating with high quality silicone to produce the PTFE film adhesive tape. With the special coating machine and accurate cutting machine , we can supply the high and consistent quality products as per our clients' requirement .
2. application
Pure Teflon/PTFE Adhesive Tape is widely applied
a. in the conduct roll for resistance of high temperature, acid ,alkali and non-stain of the surface.
b.protecting with the low friction of heating up flat .
c.pulling off of the platic model.
d.joining and binding up cable of high temperature and high –pressure with anti-static.
e. protecting with the electrical component's jointing in high temperature.
f. affixing of the hot plasticparts .
3.color: Creamy white
4.Backing: fiberglass
5.width:1250mm
6.Thickness:0.05mm 0.13mm 0.18mm 0.25mm
7.Temperature Resistance : -70°c-260°c
specification
| Item | Thickness | Max Width | Adhesion to steel | Tensile Strength | Temperature Resistance |
| omen-F7005 | 0.08mm | 1000mm | 20N/100mm | 300N/100mm | -70°c-260°c |
| omen-F7013 | 0.13mm | 1000mm | 25N/100mm | 400N/100mm | -70°c-260°c |
| omen-F7018 | 0.18mm | 1000mm | 44N/100mm | 650N/100mm | -70°c-260°c |
| omen-F7025 | 0.25mm | 1000mm | 58N/100mm | 950N/100mm | -70°c-260°c |
Pure Teflon/PTFE Adhesive Tape has been presented above, want more similar products, please click Pure Teflon PTFE Film Tape.
Our Pure Teflon/PTFE Adhesive Tape is good in quality and competitive in price. We manufacture Pure Teflon/PTFE Adhesive Tape and supply OEM, ODM service according to your requirement.
If you want more detailed information of this product or related problems, please contact with us, we will reply as soon as possible (general in 24 hours).
Category:
Electrical insulation tape
